AIRTECIntercoolerUpgradeforFiat595Abarth

AIRTEC Intercooler Upgrade for Fiat 595 AbarthGreat addition to any standard or re-mapped 595’sFast Turbo spool up by using 50mm pipe-work into the turbo and 60mm out of the turbo to help match the throttle body, this combination gives fast turbo spool up and maximum power output.Will fit any Abarth with Garrett GTI446 Turbo.AIRTEC part no: ATINTFT3Technical Data Replaces very restrictive twin intercooler setup and lengthily pipe-work, for Airtec’s high flow 60mm core intercooler and shortened alloy pipe kit, we keep fast Turbo spool up by using 50mm pipe-work into the turbo and 60mm out of the turbo to help match the throttle body, this combination gives fast turbo spool up and maximum power outputDyno test results – results taken from Fiat 500 Abarth, fitted with cat back exhaust and Airtec FMICRun 1. 120 degree into the intercooler and 22 degree out of the intercoolerRun 2. 122 degree into the intercooler and 22 degree out of the intercoolerRun 3. 123 degree into the intercooler and 22 degree out of the intercoolerConclusion, the Airtec intercooler dropped the intake temperatures by 100 degree on each run and did not suffer from heat soak.Features:60mm thick proven bar and plate core, specced to Airtec designAirtec logo’d Cast end tanks for improved Airflow and un-beatable strengthDyno proven, gain BHPLower intake temps means safer engines ‘FACT’Shorter charge pipes than standard twin intercooler set-up, short pipes mean fast turbo spool upFitting takes 2-3 hours3 year un-limited mileage warrantyAvailable in Pro-Series satin Black or Natural SilverAirtec Logo available @ no extra chargeUn-beatable value for moneyWill fit any Abarth with Garrett GTI446 Turbo.Will fit the following:Series 3 180 Competizione (Mid-Late 2015)Series 4 TurismoSeries 4 CompetizioneApproximate dimensions:Height – 205mmWidth – 820mmThickness – 65mm
